High Speed Horizontal Automatic Slitting Machine

Kostenvoranschlag erhalten

Über uns: http://wity-machinery.com/1-16-4-horizontal-slitting-machine.html

This product has been discontinued and removed from our shelves.

The DFQ-C automatic slitting machine is economical, high speed and versatile converting equipment. It can be used to slit a variety of materials such as reeled films, paper, adhesive sticker, aluminum foils, and more.

Features

1. This automatic slitter comes with high level of automation and flexibility due to an integration of control system and the machine body.
2. Its raw material holder is designed with LPC or EPC deviation control system.
3. The slitting machine applies straight slitting knife. Round knife is optional as per user's demands.
4. Designed with a constant pressure press roll for the rewinding roll, this slitter rewinder features more stable rewinding.
5. Unwinding device adopts cantilevered structure. A discharging tower structure can also be equipped according to user's requirements.
6. The unwinding device of this slitting machine comes with doffing type loading function.

Specification

Model	DFQ-C1-3	DFQ-C2-3	DFQ-C3-3
Max. unwinding diameter	￠1200mm	￠1200mm	￠1200mm
Max. rewinding diameter	￠600mm	￠600mm	￠600mm
Max. width	700mm	700mm	700mm
Min. slitting width	50mm	50mm	50mm
Web guiding control	Photocell or Ultrasonic
Precision	≤±0.5mm	≤±0.5mm	≤±0.5mm
Main driven system	Single motor	Double motor	Three motor
Control style	PLC touch screen	PLC touch screen	PLC touch screen
Tension control style	Taper automatic regulation
Mechanical speed	0-250m/min	0-350m/min	0-350m/min
Unwinding shaft	Air shaft	Air shaft	Air shaft
Rewinding shaft	Air shaft	Differential slip shaft	Air shaft or Differential slip shaft
Machine weight	About3500kg	About3500kg	About 3500kg
