Manual Fed Creasing and Die Cutting Machine (Die Cutter), ML750/930/1100/1300

Kostenvoranschlag erhalten

Über uns: http://wity-machinery.com/1-12-die-cutting-3.html

This manual die cutter is widely used to crease and die-cut ordinary cardboard, corrugated board, plastic sheet and leather products in printing, packaging and plastic industries. The machine is characterized by its compact structure, fine workmanship, high precision and easy and reliable operation, etc.

Features

High strength cast frame made by top quality materials.
Smooth running, big pressure and low noise.
Single-chip electromagnetic clutch is sensitive and reliable.
Operation altitude is rational arranged; movable platen opens to its optimum.
With continuous and delay functions, and the delaying range is adjustable.
Reliable safety protection system.
Centralized lubricating system.

Specification

Model	Inner chase size (mm)	Speed (strokes/min)	Max Rule length (m)	Motor power (kw)	Overall dimension (mm)	Weight (kg)
ML750	750×520	25	< 15	2.2	1500×1400×1300	1700
ML930	930×660	23±3	< 25	4	1720×1530×1620	2650
ML1100	1100×800	20±2	< 32	4	1860×1760×1700	4300
ML1300	1300×920	18±2	< 40	5.5	2200×2200×1750	5300
ML1400	1400×1000	18±2	< 45	5.5	2200×2200×1750	5800
ML1500	1500×1040	18±2	< 45	7.5	2500×2200×1750	6550
ML1600	1600×1250	16±2	< 50	11	2500×2200×2000	11200
ML1800	1800×1280	16±2	< 50	11	2750×2300×2500	12500
ML2000	2000×1400	14±2	< 55	15	2900×2350×2700	17000
