Double Lane Side Sealing & Cutting Bag Making Machine, DRQ-D800/1000 Manufacturer

Double Lane Side Sealing & Cutting Bag Making Machine, DRQ-D800/1000

Kostenvoranschlag erhalten

Über uns: http://wity-machinery.com/3-5-bag-making4-3.html

This Double lanes side sealing bag making machine is suitable for various kind of material such as BOPP, CPP, LDPE, HDPE, POF & laminated film,etc, either printed or plain. It is an ideal equipment for making stationery bag, ornaments bag, garment bag, food bag and hang bag.

Features

Human-computer interface, touch screen operation, motion controller control, easy to operate.
The controller takes synchronous control of the main motor speed, material pulling speed and the material unwinding speed.
Driven by servo motor, photo sensor tracks the accurate printings, automatic alarm if the photo sensor unavailable.
Main motor controlled by frequency inverter, easy to operate, save the power consumption, bags come out stably .
Customized knife, bags well collected and sealed.
Supported by automatic web-guiding film folder and automatic bag sorter, it constitutes the complete assembly line, which greatly promotes the production efficiency(Optional)

Specification

Model	DRQ-D800	DRQ-D1000
Max.bag Width	370mm*2	470*2
Bag Length	70-650mm	70-650mm
Film thickness	0.02-0.1mm	0.02-0.1mm
Speed	300pcs/min×2	300pcs/min×2
Power supply	380V/50HZ	380V/50HZ
Max.Unwinding diameter	Ф550mm	Ф550mm
Air compressor	5HP	5HP
Total power	15 KW	15KW
Weight	1050KG	1150KG
Size(LWH)	1680×1320×1200mm	1680×1320×1200mm (Auto bag stacking)
	3000×1500×1300mm	3000×1700×1300mm (Bag making)
	1900×1800×1400mm	2100×2000×1400mm (Film folding)
	1800×1300×1350mm	1800×1500×1350mm (Multifunctional frame)
