Multi-functional Vertical Type Laminating Machine (Film Laminator)
Kostenvoranschlag erhalten
The multi-functional vertical type laminating machine supports lamination with both water-based glue and pre-coated film. This product is distinguished by advanced structure, high automation, simple operation, and high cost performance. Our automatic film laminator is widely used by packaging material industry and the printing plant for books, periodicals, and some others. The high-efficiency vertical laminator is also an ideal choice for other commercial use.
Features
- The multi-function vertical type laminating machine adopts a material feeder characterized by high speed and easy operation.
- The non-stop paper feeding and paper collection effectively shorten the service working time for lamination.
- High-efficiency oil heating system for the multi-function vertical type laminating machine helps the roller for hot pressing achieve uniform and constant temperature.
- Chrome plated roller for surface sizing is employed, resulting in less glue consumption and uniform gelatinizing.
- For optimal drying capacity, the multi-function laminating equipment adopts hot air drying system.
- The unwinding mechanism is specially designed for the lamination on thin paper.
Specification
| Model | FM-1050 (with paper sheeter) | FM-1050(without paper sheeter) |
| Max laminating width | 1050mm | 1050mm |
| Laminating speed | 5-40m/min | 5-40m/min |
| Total power | 46kw | 45kw |
| Pressing temperature | 30-120℃ | 30-120℃ |
| Laminating pressure | 5-15Mpa | 5-15Mpa |
| Overall dimension | 6500x2000x2300mm | 3000x2000x2300mm |
| Machine weight | 4500kg | 3500kg |
